This series of pendant lights offers a diverse range of LED sources, including options in RGB + Warm White, Variable White and single colour (3000K, 4000K and 5600K), each featuring a 50 Watt LED that provides high-quality light output, uniform colour, and remarkable durability.

Completed by a wide range of optics, accessories, and versatile mounting solutions, the EclPendant S adapts to various installation needs. Mounting alternatives include pendant, surface, stem, wall, adjustable bracket, and recessed options. It can be directly wired to mains power (100-240 VAC or 48 VDC) and integrates seamlessly with control protocols like DMX + RDM and DALI, thanks to its accessible terminal blocks.

User-friendly settings are manageable via the unit's onboard GUI, enhancing its functionality. The fixture's wide array of optics and accessories is designed for utmost flexibility and precision, allowing easy on-site changes without complications.

Notably, the EclPendant S features a fan-free thermal design, ensuring quiet operation while delivering consistent and robust lumen output throughout its extended lifespan.

- Source: 50W White COB LED
- Source CCT: 3000K (TU), 4000K (NW), 5600K (DY)
- Luminous flux: (TU) 2,814 lm; (NW) 3,851 lm; (DY) 4,045 @ full
- Lux: (TU) 796 lx; (NW) 1,079 lx; (DY) 1,116 lx @ 5m full
- CRI: (TU) 98.1; (NW) 95.3; (DY) 95.2
- R9: (TU) 91.8; (NW) 89.2; (DY) 91.8
- TLCI: (TU) 98; (NW) 96; (DY) 96
- TM30 Rf: (TU) 93.4; (NW) 92.3; (DY) 90.9
- TM30 Rg: (TU) 99.1; (NW) 101.3; (DY) 100.8
- Source life expectancy: > 50,000 hrs (L70B10 @ Ta 25° C / 77° F)
- Beam angle: 20°
- Field angle: 40°
- Lens diameter: 100mm / 4''
- Lens type: Fresnel lens
- Other: see available accessories

- Static mode: selection of static dimmer
- Manual mode: manual adjustment of dimmer and strobe
- Auto mode: built-in programs with execution speed adjustment

- Supported Protocols: DALI Type6, DMX512, RDM, CRMX (optional)
- DMX channels: UNO / DUO / Standard / Extendedch
- RDM: for remote addressing and parameter configuration
- Display: Graphic User Interface
- Other: 16bit control of dimmer
