EclProfile FWVW Range

PROLIGHTS EclProfile FWVW IP - pointing up

EclProfile FWVW Range

Key Features:

Linear CCT control 2,700K - 5,600K

High lumen output and superior quality of whites (high CRI, TLCI, TM30)

Silent operation and compatible with industry standard accessories

Enquire

Enquiry Form

Call us today on

+44 (0)1494 446000

EclProfile FWVW Range

The PROLIGHTS EclProfile FWVW is a high quality variable white LED ellipsoidal, with linear CCT 2,700K - 5,600K.

Product Variants

PROLIGHTS EclProfile FWVW

IP20

Enquiry Form

PROLIGHTS EclProfile FWIPVW

IP65

Enquiry Form

The EclProfile FWVW has the same housing and optical design as the FC version. For those requiring higher brightness and quality on a specific point, the EclProfile offers superior evenness and crisp focus.

The LED source achieves the finest quality of whites and has high values of CRI, R9 and TM30. The fixture is ideal for applications including corporate events, advertising and exhibitions.

Source: 91x3W high-power white LED

CCT: from 2,700K to 5,600K

Luminous flux: (26° TU) 3,696lm; (26° DY) 4,406lm; (26°) 7,951lm @ full

Lux: (26° TU) 1,289lx; (26° DY) 1,524lx; (26°) 2,759lx @ 5m full

CRI (IP20): (TU) 97; (DY) 97.4; (@ full) 95.4

CRI (IP65): (TU) 97.7; (DY) 95.7; (@ full) 96.3

Source life expectancy: > 50,000hr (L70B10 @ Ta 25° C / 77° F)

Optics

Beam angle: optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50°

Lens type: HD anti-reflection lenses with achromatic coating

Focus: manual

Gobo size: B, outer: 86mm – image: 64.5mm – thickness: 1.1mm

Static mode: selection of static dimmer

Manual mode: manual adjustment of dimmer and strobe

Auto mode: built-in programs with execution speed adjustment

Special features: HIGH mode, AUTO mode and SILENT mode fan management

Protocols: DMX512, RDM

DMX channels (IP20): 1 / 2 / 3 / 5 / 11 channel

DMX channels (IP65): 2 / 3 / 4 / 6 / 12 channel

RDM: RDM for remote monitoring and settings

Display: graphic user interface

Firmware upgrade: yes, via USB – DMX interface (UPBOX2) not included

Master/slave: for synchronised operation of more units linked in a chain
