On-board Screen: 10.1” Full Color Touchscreen
Playback Faders: 6 linear faders
Playback Encoders: 6 rotary push-encoders with RGB backlight
Value Encoders: 8 rotary push-encoders with RGB backlight
DMX Channels: 2048ch
DMX universes: 4 DMX universes freely mappable between CRMX, DMX, ArtNet, s-ACN
Playback Pages: 99 + 1 Template Page
Memories: 250 Presets per Feature Group, 100 Fixture-Groups
Max Fixtures: Limited by DMX Channels
External Control: MIDI trigger. MIDI Timecode, OSC
Software update: via USB stick or online server (requires internet connection)
Library update: via USB stick or online server (requires internet connection)
DMX out: 2 freely mappable
ArtNet: 4 universes, freely mappable
sACN: 4 universes, freely mappable
MIDI: In / Through / Out
Wireless: 2x DMX universes freely assignable to any of the TimoTwo LumenRadio modules — CRMX or W-DMX, with Bluetooth support
External Display: 1 HDMI out
Hardware on-board: Tilt adjustament bar
Body: sturdy policarbonate body
Low Voltage DC mains: 24V via DC IN through external power supply, 14,4-28,8V with V-Lock batteries connection
Max power consumption: 40W
Standby power: 23 W
Battery: 24V compatible with external power supply and V-Mounts batteries (14.4-28.8Vdc) - battery not included
Operating Temperature: 0° ~ +45°
IP rating: IP20
Cooling: passive cooling and fan-free
Data: 3 x USB ports (1 on the top, 2 on the back)
Signal connection: 2 x Seetronic XLR 5p OUT connector
Data connection: 1 x RJ45 IN/OUT
Wireless Antenna: 2 RP-TNC female connector
Low Voltage DC connector: XLR 4P for 24V, 2 x V-Mount adapter (14,4V)
Dimensions (WxHxD): 374x98x356mm / 14.72''x3.86''x14.02''
Weight: 4,1kg / 9.04lbs
